| SPECIFICATIONS | |
|---|---|
| SIZES | 2" TO 100", LARGE SIZES ALSO AVAILABLE UPON REQUEST |
| CLASS RATINGS | CL 150 TO 600, HIGH PRESSURE CLASSES ALSO AVAILABLE UPON REQUEST |
| APPLICATION | METERING SKIDS FINDS APPLICATION IN THE FOLLOWING APPLICATIONS. 1. ONSHORE/OFFSHORE GAS CUSTODY 2. TRANSFER METERING 3. PIPELINE BIDIRECTIONAL MEASUREMENTS 4. GAS TERMINALS AND MIXING STATIONS 5. GAS POWER PLANTS 6. PIPELINE JUNCTIONS 7. COMPRESSOR STATIONS 8. CHEMICAL COMPANIES 9. CITY GATE FACILITIES ETC. |
| FEATURES AND BENEFITS | THE FOLLOWING ARE SOME ADVANTAGES OF METERING SKID. 1. EASY TRANPORTABILITY 2. MINIMAL SITE WORK 3. PLUG & PAY 4. PRE-DEFINED SKID LAYOUT |
| STANDARD | REFERENCE |
|---|---|
| DESIGN & MANUFACTURING | ASME B16.34, ASME BPVC SECTION VIII & IX, ASME B16.42/ API 5L M-CR-630 MANUFACTURING STANDARD |
| FACE TO FACE | MANUFACTURING STANDARD |
| END CONNECTION | ASME B16.5, ASME B16.47 SERIES A & B, EN 10092-1, NORSOK U-001 |
| TESTING | API 598, EN 12266 - 1 & 2, BS 6755 PART-1, ISO 5208, EN 10204, ASME B16.34, AS PER CUSTOMER STANDARDS / SPECIFICATIONS |
| NACE COMPLIANCE | NACE MR 0175 / ISO 15156, NACE MR 0103 |
| PT RATING | ASME B16.34, MANUFACTURING STANDARD |
| MATERIAL OF CONSTRUCTION | |
|---|---|
| VALVES / STRUCTURES | CARBON STEEL (CS), LOW TEMPERATURE CARBON STEEL (LTCS), OTHER MATERIALS ALSO AVAILABLE UPON CUSTOMER REQUIREMENT. |
| PIPINGS | CARBON STEEL (CS), LOW TEMPERATURE CARBON STEEL (LTCS), OTHER MATERIALS ALSO AVAILABLE UPON CUSTOMER REQUIREMENT. |
| SEALING ELEMENT | PTFE, RPTFE, NYLON, OTHER SPECIAL MATERIALS |
| O-RINGS | VITON, NBR, EPDM, OTHER SPECIAL MATERIALS |
| FASTENERS | ASTM A193 Gr.B7 / A194 Gr.2H, ASTM A193 Gr.B7M / A194 Gr.2HM, ASTM A320 Gr.L7 / A194 Gr.7, ASTM A320 Gr.L7M / A194 Gr.7M, ASTM A193 Gr.B16 / A194 Gr.4, OTHER SPECIAL MATERIALS |
